Shantui Spare Parts SD22 Valve 701-30-99000
Part Name:Valve
Part Number: 701-30-99000
Machine Model:SD22
| NO. | PART NO. | Q'TY | MODEL | |
| PART NAME | ||||
| 0 | 701-32-42001 | Main valve ass'y | 1 | |
| 1 | 701-31-32112 | Valve body | 1 | |
| 2 | 701-33-31430 | Spool valve | 1 | |
| 3 | 07043-70312 | Plug | 1 | |
| 4 | 701-33-31120 | Valve | 1 | |
| 5 | 701-33-31130 | Spring | 1 | |
| 6 | 701-33-31150 | Bracket | 1 | |
| 7 | 07000-13035 | O-ring | 1 | |
| 8 | 701-33-31160 | Bolster | 1 | |
| 9 | 01010-51235 | Bolt | 2 | |
| 10 | 01602-21236 | Washer | 7 | |
| 11 | 701-33-31380 | Retaining ring | 2 | |
| 12 | 701-33-31191 | Spring | 1 | |
| 13 | 01010-51245 | Bolt | 2 | |
| 14 | 701-33-46171 | Casing | 1 | |
| 15 | 01010-51280 | Bolt | 1 | |
| 16 | 01011-51210 | Bolt | 2 | |
| 17 | 701-33-46340 | Plate | 1 | |
| 18 | 01010-51095 | Bolt | 2 | |
| 19 | 01602-21030 | Washer | 2 | |
| 20 | 07000-13045 | O-ring | 3 | |
| 21 | 07000-12015 | O-ring | 14 | |
| 22 | 07000-13030 | O-ring | 2 | |
| 23 | 701-33-31360 | Plate | 1 | |
| 24 | 07000-13040 | O-ring | 1 | |
| 25 | 01010-51440 | Bolt | 2 | |
| 26 | 01602-21442 | Washer | 2 | |
| 27 | 701-30-99000 | Valve | 1 |
